MRH120, 8.1 mm 0.32 in Stroke, Hollow Plunger Hydraulic Cylinder
-
Model:MRH120
Maximum Operating Pressure: 5000 PSI | 350 bar
Maximum Cylinder Capacity Advance: 13800 lbs | 61.4 kN
Stroke: 0.32 in | 8.1 mm
Material: Steel
Weight: 3.1 lbs | 1.4 kg
Manufacturer:Axion
Return Type:Single-Acting Spring Return
Plunger Type:Hollow
Brand Name:Replacement Enerpac's MRH120
- RCH Series Single-Acting Hollow CylindersMRH120, 8.1 mm 0.32 in Stroke, Hollow Plunger Hydraulic CylinderMRH20, 8.4 mm 0.33 in Stroke, Hollow Plunger Hydraulic CylinderRCH1003,100 ton 947 KN,76 mm 2.99 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH606,60 ton 589 KN,153 mm 6.02 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH603,60 ton 589 KN,76 mm 2.99 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH306,30 ton 336 KN,155 mm 6.10 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH302, 30 ton 336 KN,64 mm 2.52 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH206, 20 ton 236 KN,155 mm 6.10 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH202, 20 ton 236 KN,49 mm 1.93 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH123, 13 ton 127 KN,76 mm 2.99 in Stroke, Single Acting Hollow PLunger Hydraulic CylinderRCH121, 13 ton 127 KN,42 mm 1.65 in Stroke, Single Acting Hollow PLunger Hydraulic Cylinder
Description
Model:MRH120
Product Line: Industrial Tools
Type: Hydraulic Cylinder Ram, Hydraulic Jacks
Customizable with special requirement
The cylinder's design allows for flexible loading options, enabling both push and pull actions by attaching a load to either end. Its high capacity and compact size contribute to efficient fixture design. The Spring Return feature simplifies workpiece unloading, while threaded collars and base mounting holes offer versatile installation options. Nickel-plated plungers and wipers, along with internal venting, enhance corrosion resistance and extend the cylinder's lifespan.
Center Hole Diameter Y: 0.77 in
Cylinder Effective Area Advance: 2.76 in²
Oil Capacity Advance: 0.86 in³
Series Comparison
| Product | Maximum Operating Pressure (psi/bar) | Maximum Cylinder Capacity Advance (lbs/kN) | Stroke (in/mm) | Center Hole Diameter Y (in) | Return Type | Plunger Type | Material | Cylinder Effective Area Advance (in2) | Oil Capacity Advance (in3) | Weight (lbs/kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| MRH20 | 3000 | 210 | 4000 | 17.8 | 0.33 | 8.4 | 0.5 | Single-Acting, Spring Return | Hollow | Steel | 1.33 | 0.41 | 1.3 | 0.6 |
| MRH120 | 5000 | 350 | 13800 | 61.4 | 0.32 | 8.1 | 0.77 | Single-Acting, Spring Return | Hollow | Steel | 2.76 | 0.86 | 3.1 | 1.4 |
Application
Wind turbines require periodic maintenance, and hydraulic cylinder jacksenable technicians to reach and service these towering structures.
Railways use hydraulic cylinder jacks to lift locomotives, allowing access for inspections and maintenance.
Hydraulic cylinder jacks provide the lifting power needed to assemble large structures such as steel frameworks and industrial buildings.
Hydraulic cylinder jacksassist in lifting heavy materials to build retaining walls, ensuring proper alignment and stability.
Hydraulic cylinder jacks help position utility poles securely during installation, ensuring the stability of power and communication lines.
Overhead cranes require precise positioning during installation, which hydraulic cylinder jacksfacilitate.
In the renewable energy sector, hydraulic cylinder jacks are used to position and adjust solar panel arrays for optimal sun exposure and energy generation.
PROVIDING EXCELLENT SOLUTIONS BY Axion™
You're fortunate to have found a manufacturer, supplier, and factory in China, Ningbo Axion Machinery Co., Ltd.,
that offers a diverse selection, reasonable price,fast delivery, and products of comparable quality and performance to Enerpac's MRH120, 8.1 mm 0.32 in Stroke, Hollow Plunger Hydraulic Cylinder.
Please send an email immediately with information regarding the "MRH120, 8.1 mm 0.32 in Stroke, Hollow Plunger Hydraulic Cylinder" You will receive our response within 24 hours.
