RACL10010,100 Ton,250 mm,Single Acting Aluminum Lock Nut Hydraulic Cylinders
-
Model:RACL10010
Capacity:100 ton
Stroke:250 mm | 9.84 inches
Weight:31.1 kg | 68.6 lbs
Push Oil Capacity:3578 cm³
Warranty:12 months
Minimum Order:1 Pieces
Manufacturer:Axion
Country of Origin:China
Maximum Operating Pressure:700 Bar/10000 Psi
Return Type:Single-Acting Spring Return
Plunger Type:Solid
Brand Name:Replacement Enerpac's RACL10010
- RACL15010,150 Ton,250 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1508,150 Ton,200 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1506,150 Ton,150 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1504,150 Ton,100 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1502,150 Ton,50 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL10010,100 Ton,250 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1008,100 Ton,200 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1006,100 Ton,150 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1004,100 Ton,100 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL1002,100 Ton,50 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL5010,50 Ton,250 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL508,50 Ton,200 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL506,50 Ton,150 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL504,50 Ton,100 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL502,50 Ton,50 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL3010,30 Ton,250 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL308,30 Ton,200 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL306,30 Ton,150 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL304,30 Ton,100 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL302,30 Ton,50 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL2010,20 Ton,250 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL208,20 Ton,200 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL206,20 Ton,150 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL204,20 Ton,100 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL202,20 Ton,50 mm,Single Acting Aluminum Lock Nut Hydraulic CylindersRACL Series Single-Acting,Aluminium Lock Nut Cylinders
Description
Model:RACL10010
Product Line: Industrial Tools
Type: Hydraulic Cylinder Ram, Hydraulic Jacks
Customizable with special requirement
Hollow Plunger design: Suitable for both pulling and pushing forces, increasing versatility.
Composite bearings: Extend service life and enhance side load resistance.
Hard-coat finish: Provides all-around surface protection and extends product life.
Floating center tube: Reduces seal wear and extends service life.
Standard handles: Facilitate operation and positioning.
Steel base plate and saddle: Enhance load-bearing capacity and protect against load-induced damage.
Integral stop ring: Prevents plunger overtravel and withstands full cylinder capacity.
High-strength return spring: Ensures rapid cylinder retraction.
Aluminum lock nut: Provides long-term mechanical load holding.
Hardened steel stop ring: Extends service life and enhances side load resistance (up to 5%).
CR-400 coupler and dustcap: Included with all models.
Need a custom fit? Our OEM services let you tailor Products to your specific needs. Contact our sales team today!
Image Gallery
Dimensions
| Collapsed Height/mm(A) | 496 |
| Extended Height/mm(B) | 746 |
| Outside Dia/mm(D) | 180 |
| Cylinder Bore Dia/mm(E) | 135 |
| Plunger Dia/mm(F) | Tr 110 x 6 |
| Base To Advance Port/mm(H) | 46 |
| Saddle Dia/mm(J) | 94 |
| Saddle Protri. From Plgr./mm(K) | 3 |
| Dimension S | 75 |
Series Comparison
| Model Number | Capacity/Ton | Stroke/mm | Cylinder Effective Area/cm2 | Oil Capacity/cm3 | Collapsed Height/mm(A) | Extended Height/mm(B) | Outside Dia/mm(D) | Cylinder Bore Dia/mm(E) | Plunger Dia/mm(F) | Base To Advance Port/mm(H) | Saddle Dia/mm(J) | Saddle Protri. From Plgr./mm(K) | Dimension S | Weight/Kg |
| RACL-202 | 20 | 50 mm | 1.97 inches | 31.2 | 156 | 224 | 274 | 85 | 63 | Tr 55 x 4 | 27 | 40 | 3 | 50 | 4 kg | 8.8 lbs |
| RACL-204 | 20 | 100 mm | 3.94 inches | 31.2 | 312 | 274 | 374 | 85 | 63 | Tr 55 x 4 | 27 | 40 | 3 | 50 | 4.6 kg | 10.1 lbs |
| RACL-206 | 20 | 150 mm | 5.91 inches | 31.2 | 468 | 324 | 474 | 85 | 63 | Tr 55 x 4 | 27 | 40 | 3 | 50 | 5.2 kg | 11.5 lbs |
| RACL-208 | 20 | 200 mm | 7.87 inches | 31.2 | 624 | 374 | 574 | 85 | 63 | Tr 55 x 4 | 27 | 40 | 3 | 50 | 5.8 kg | 12.8 lbs |
| RACL-2010 | 20 | 250 mm | 9.84 inches | 31.2 | 780 | 424 | 674 | 85 | 63 | Tr 55 x 4 | 27 | 40 | 3 | 50 | 6.4 kg | 14.1 lbs |
| RACL-302 | 30 | 50 mm | 1.97 inches | 44.2 | 221 | 231 | 281 | 100 | 75 | Tr 60 x 4 | 33 | 40 | 3 | 50 | 5.4 kg | 11.9 lbs |
| RACL-304 | 30 | 100 mm | 3.94 inches | 44.2 | 442 | 281 | 381 | 100 | 75 | Tr 60 x 4 | 33 | 40 | 3 | 50 | 6.1 kg | 13.4 lbs |
| RACL-306 | 30 | 150 mm | 5.91 inches | 44.2 | 663 | 331 | 481 | 100 | 75 | Tr 60 x 4 | 33 | 40 | 3 | 50 | 6.8 kg | 15.0 lbs |
| RACL-308 | 30 | 200 mm | 7.87 inches | 44.2 | 883 | 381 | 581 | 100 | 75 | Tr 60 x 4 | 33 | 40 | 3 | 50 | 7.5 kg | 16.5 lbs |
| RACL-3010 | 30 | 250 mm | 9.84 inches | 44.2 | 1105 | 431 | 681 | 100 | 75 | Tr 60 x 4 | 33 | 40 | 3 | 50 | 8.2 kg | 18.1 lbs |
| RACL-502 | 50 | 50 mm | 1.97 inches | 70.9 | 354 | 236 | 286 | 130 | 95 | Tr 80 x 4 | 30 | 50 | 3 | 50 | 9.3 kg | 20.5 lbs |
| RACL-504 | 50 | 100 mm | 3.94 inches | 70.9 | 709 | 286 | 386 | 130 | 95 | Tr 80 x 4 | 30 | 50 | 3 | 50 | 10.6 kg | 23.4 lbs |
| RACL-506 | 50 | 150 mm | 5.91 inches | 70.9 | 1063 | 336 | 486 | 130 | 95 | Tr 80 x 4 | 30 | 50 | 3 | 50 | 11.9 kg | 26.2 lbs |
| RACL-508 | 50 | 200 mm | 7.87 inches | 70.9 | 1417 | 386 | 586 | 130 | 95 | Tr 80 x 4 | 30 | 50 | 3 | 50 | 13.2 kg | 29.1 lbs |
| RACL-5010 | 50 | 250 mm | 9.84 inches | 70.9 | 1771 | 436 | 686 | 130 | 95 | Tr 80 x 4 | 30 | 50 | 3 | 50 | 14.5 kg | 32.0 lbs |
| RACL-1002 | 100 | 50 mm | 1.97 inches | 143.1 | 716 | 296 | 346 | 180 | 135 | Tr 110 x 6 | 46 | 94 | 3 | 75 | 21.9 kg | 48.3 lbs |
| RACL-1004 | 100 | 100 mm | 3.94 inches | 143.1 | 1431 | 346 | 446 | 180 | 135 | Tr 110 x 6 | 46 | 94 | 3 | 75 | 24.2 kg | 53.4 lbs |
| RACL-1006 | 100 | 150 mm | 5.91 inches | 143.1 | 2147 | 396 | 546 | 180 | 135 | Tr 110 x 6 | 46 | 94 | 3 | 75 | 26.5 kg | 58.4 lbs |
| RACL-1008 | 100 | 200 mm | 7.87 inches | 143.1 | 2863 | 446 | 646 | 180 | 135 | Tr 110 x 6 | 46 | 94 | 3 | 75 | 28.8 kg | 63.5 lbs |
| RACL-10010 | 100 | 250 mm | 9.84 inches | 143.1 | 3578 | 496 | 746 | 180 | 135 | Tr 110 x 6 | 46 | 94 | 3 | 75 | 31.1 kg | 68.6 lbs |
| RACL-1502 | 150 | 50 mm | 1.97 inches | 227 | 1135 | 323 | 373 | 230 | 170 | Tr 140 x 6 | 51 | 113 | 3 | 80 | 32.2 kg | 71.0 lbs |
| RACL-1504 | 150 | 100 mm | 3.94 inches | 227 | 2270 | 373 | 473 | 230 | 170 | Tr 140 x 6 | 51 | 113 | 3 | 80 | 36.2 kg | 79.8 lbs |
| RACL-1506 | 150 | 150 mm | 5.91 inches | 227 | 3405 | 423 | 573 | 230 | 170 | Tr 140 x 6 | 51 | 113 | 3 | 80 | 40.2 kg | 88.6 lbs |
| RACL-1508 | 150 | 200 mm | 7.87 inches | 227 | 4540 | 473 | 673 | 230 | 170 | Tr 140 x 6 | 51 | 113 | 3 | 80 | 44.2 kg | 97.4 lbs |
| RACL-15010 | 150 | 250 mm | 9.84 inches | 227 | 5675 | 523 | 773 | 230 | 170 | Tr 140 x 6 | 51 | 113 | 3 | 80 | 48.2 kg | 106.3 lbs |
Application
Construction equipment often requires precise positioning for maintenance and repair tasks, and hydraulic cylinder jacks provide the necessary lifting capability.
Hydraulic cylinder jacksaid in lifting and positioning heavy materials and equipment within manufacturing facilities.
Wind turbines require periodic maintenance, and hydraulic cylinder jacksenable technicians to reach and service these towering structures.
Welders use hydraulic cylinder jacksto accurately position heavy workpieces for welding tasks, ensuring precision and safety.
Aircraft maintenance crews rely on hydraulic cylinder jacksto raise aircraft for inspection and repairs.
Hydraulic cylinder jacksassist in lifting heavy materials to build retaining walls, ensuring proper alignment and stability.
In the renewable energy sector, hydraulic cylinder jacks are used to position and adjust solar panel arrays for optimal sun exposure and energy generation.
